5.10. Ripple

5.10. Ripple
	5. Distort Filters

Figure 17.75. “Ripple” filter example

Original image

Filter “Ripple” applied

It displaces the pixels of the active layer or selection to waves or ripples reminding a reflection on disturbed water.

This filter is found in the main menu under Filters → Distorts → Ripple….

Figure 17.76. “Ripple” filter options

Presets, “Input Type”, Clipping, Blending Options, Preview, Merge filter, Split view

	Note
	These options are described in Section 2, “Common Features”.

Original images for examples

Origin

Ripple applied with default options

Amplitude

It is related to wave height (0-200 pixels).

Amplitude = 25

Period

It is related to wavelength (0-200 pixels)

Period = 110

Phase shift

Wave is moved

Phase shift = 0.400

Angle

Warps wave

Angle = -40°

Resampling methods

These interpolation methods are described in Interpolation.

Wave type

Choose how the wave should look like:

Abyss policy

Because ripples cause pixel displacement, some pixels may be missing on the image sides:

Abyss policy = Black

Abyss policy (border management) is treated with Abyss policy.

Tileable

This preserves the seamless properties if your image is a tile pattern.
