| 5.12. Spherize | ||
|---|---|---|
|
5. Distort Filters |  |
| 5.12. Spherize | ||
|---|---|---|
|
|
5. Distort Filters | |
This filter creates a kind of bubble whose size is that of the image or selection, as if the content was wrapped around a sphere.
Рисунок 17.79. Spherize filter example, with default values
Original image
«Spherize» filter applied
![[Примітка]](images/note.png)
|
Примітка |
|---|---|
|
These options are described in Розділ 2, «Common Features». |
Radial is the default mode. See example above.
Horizontal: as if image was mapped on a vertical cylinder.
Vertical: as if image was mapped on a horizontal cylinder.
Camera angle of view (0 - 180°)
Spherical cap angle, as a fraction of the co-angle (complement angle) of view. Result is less domed as curvature decreases (100% - 0).
Interesting for negative values, which result in a hollow instead of a bump (from 1.000 to -1.000).
These interpolation methods are described in Interpolation.
Drawing a selection before applying filter allows you to create another shape, such as a sphere: select Ellipse tool with the Fixed option checked; draw a circle; apply Spherize filter with the Use the selection as input selected. Invert selection and fill it with wanted background.
